DigiDesign C24 User Manual

Chapter 5: Connecting Your Studio 31
Monitoring System Inputs
Monitor Inputs and Cue Inputs
Alternate Surround Inputs
External Stereo Inputs
Monitoring System Outputs
Main Outputs (5.1) and Alternate Outputs
Main Outputs (LCRS) and Alternate Outputs
Alternate Outputs (Stereo)
Pro Tools In (PT 1-6 + Cue 1-2)
Chan Signal
1 Main Input Left (L) from Pro Tools Out 1
2 Main Input Center (C) from Pro Tools Out 2
3 Main Input Right (R) from Pro Tools Out 3
4 Main Input L Surr (Ls) from Pro Tools Out 4
5 Main Input R Surr (Rs) from Pro Tools Out 5
6 Main Input LFE (LFE) from Pro Tools Out 6
7 Cue Input Left from Pro Tools Cue Out 1
8 Cue Input Right from Pro Tools Cue Out 2
Surround In (Alt Sur 1-6)
Chan Signal
1 Alt Input Left (L) from DVD player
2 Alt Input Center (C) from DVD player
3 Alt Input Right (R) from DVD player
4 Alt Input Left Surround (Ls) from DVD
player
5 Alt Input Right Surround (Rs) from DVD
player
6 Alt Input LFE (LFE) from DVD player
Ext Stereo In (Ext St 1 + St 2)
Chan Signal
1 Ext Stereo 1 In Left from CD player
2 Ext Stereo 1 In Right from CD player
3 Ext Stereo 2 In Left from DAT deck
4 Ext Stereo 2 In Right from DAT deck
Control Room Out (5.1 Mon Out L:1 R:3)
Chan Signal
1 Main Output Left (L) to Left speaker
2 Main Output Center (C) to Center speaker
3 Main Output Right (R) to Right Speaker
4 Main Output Left Surround (Ls) to Left
Surround speaker
5 Main Output Right Surround (Rs) to Right
Surround speaker
6 Main Output LFE (LFE) to Subwoofer
7 Alt (Stereo) Output Left to Alt speaker L
8 Alt (Stereo) Output Right to Alt speaker R
Control Room Out (5.1 Mon Out L:1 R:3)
Chan Signal
1 Main Output Left (L) to Left speaker
2 Main Output Center (C) to Center speaker
3 Main Output Right (R) to Right Speaker
4 Main Output Left Surround (Ls) to Surround
speaker (or split to 2 Surround speakers)
5 no connection
6 no connection
7 Alt (Stereo) Output Left to Alt speaker L
8 Alt (Stereo) Output Right to Alt speaker R
Alt Outputs (Alt Out L-R on 1/4-inch TRS connectors)
Chan Signal
1 Alt (Stereo) Output Left to Alt speaker L
2 Alt (Stereo) Output Right to Alt speaker R
