C|24 Guide22
Line Submixer
C|24 provides an 8x2 Line Submixer that can be
used to mix instrument inputs, auxiliary re-
turns, or other external sources to stereo.
The output of the Line Submixer can then be
connected to Pro Tools audio interface inputs
for recording, or it can be monitored through
the Monitor section of C|24.
The built-in Line Submixer operates indepen-
dently of Pro Tools and can be used whenever
C|24 is powered on.
Line Submixer Inputs
C|24 Line Submixer inputs appear as two groups
of 4 stereo inputs (1-4, 5-8) on the back panel.
Each group of stereo inputs has a DB-25 female
connector, labeled as follows:
• Submix In 1-4 (ST)
• Submix In 5-8 (ST)
Each of the 8 submixer inputs has an indepen-
dent gain control on the top panel.
Line Submixer input connections are shown in
the following tables.
Line Submixer Outputs
Stereo Outputs C|24 Line Submixer outputs ap-
pear as a pair of line-level outputs (L-R) on the
back panel. Each output has a 1/4-inch balanced
TRS connector, labeled as follows:
•Submix Out L
•Submix Out R
Stereo Output to Monitor Section C|24 Sub-
mixer outputs (L-R) can also be routed to the
Left and Right channels of the C|24 Monitor sec-
tion using the “To Mon” switch on the top
panel of C|24. This is useful for monitoring your
studio equipment when you are not running
Pro Tools.
The submixer output level is controlled with the
Master level control on the top panel.
Submix In 1-4
Channel Signal
1 Submixer Input 1 (Left)
2 Submixer Input 1 (Right)
3 Submixer Input 2 (Left)
4 Submixer Input 2 (Right)
5 Submixer Input 3 (Left)
6 Submixer Input 3 (Right)
7 Submixer Input 4 (Left)
8 Submixer Input 4 (Right)
Submix In 5-8
Channel Signal
1 Submixer Input 5 (Left)
2 Submixer Input 5 (Right)
3 Submixer Input 6 (Left)
4 Submixer Input 6 (Right)
5 Submixer Input 7 (Left)
6 Submixer Input 7 (Right)
7 Submixer Input 8 (Left)
8 Submixer Input 8 (Right)
Submix Out 1-2
Channel Signal
1 Submix Out (Left)
2Submix Out (Right)
