DigiDesign C24 User Manual

Chapter 4: Audio Connections 21
Mic/Line/DI Preamp Outputs
C|24 Mic/Line/DI preamplifier outputs appear
in two groups of 8 line-level outputs (1-8, 9-16)
on the back panel. Each group of outputs has a
DB-25 female connector, labeled as follows:
•Line Out 1-8
• Line Out 9-16
Mic/Line/DI preamplifier outputs are shown in
the following tables.
Line Outputs
Line In 9-16
Channel Signal
1 Line In 9
2 Line In 10
3 Line In 11
4 Line In 12
5 Line In 13
6 Line In 14
7 Line In 15
8 Line In 16
DI In 9-10 (overrides Mic/Line In 9-10)
Channel Signal
1 Line In 9
2 Line In 10
Line Out 1-8
Channel Signal
1Line Out 1
2Line Out 2
3Line Out 3
4Line Out 4
5Line Out 5
6Line Out 6
7Line Out 7
8Line Out 8
Line Out 9-16
Channel Signal
1Line Out 9
2Line Out 10
3Line Out 11
4Line Out 12
5Line Out 13
6Line Out 14
7Line Out 15
8Line Out 16

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
