DigiDesign C24 User Manual

Appendix A: C|24 Connector Pinouts 107
Appendix A: C|24 Connector Pinouts
Female DB-25 Connectors
All C|24 DB-25 connector pinouts conform to
the pin numbering scheme shown below.
Preamps 1–8
Mic In 1–8
Line/DI In 1–8
DB-25 Connector (user view)
Mic Preamp Inputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Mic In 1
24 12 25
2 Preamp
Mic In 2
10 23 11
3 Preamp
Mic In 3
21 9 22
4 Preamp
Mic In 4
7208
113
1425
5 Preamp
Mic In 5
18 6 19
6 Preamp
Mic In 6
4175
7 Preamp
Mic In 7
15 3 16
8 Preamp
Mic In 8
1142
Mic Preamp Inputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Line In 1
24 12 25
2 Preamp
Line In 2
10 23 11
3 Preamp
Line In 3
21 9 22
4 Preamp
Line In 4
7208
5 Preamp
Line In 5
18 6 19
6 Preamp
Line In 6
4175
7 Preamp
Line In 7
15 3 16
8 Preamp
Line In 8
1142
Mic Preamp Inputs 1–8
Channel Hot (+) Cold (–) Ground (shield)

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
