DigiDesign C24 User Manual

C|24 Guide110
Submix In 5–8 (ST)
Monitor Section
Pro Tools In
Pt 1–6 + Cue 1–2
Submixer Stereo Inputs 5–8
Channel Hot (+) Cold (–) Ground (shield)
1
Submixer
In 5 Left
24 12 25
2
Submixer
In 5 Right
10 23 11
3
Submixer
In 6 Left
21 9 22
4
Submixer
In 6 Right
7208
5
Submixer
In 7 Left
18 6 19
6
Submixer
In 7 Right
4175
7
Submixer
In 8 Left
15 3 16
8
Submixer
In 8 Right
1142
Pro Tools and Cue Inputs
Channel Hot (+) Cold (–) Ground (shield)
1 Main In
Left
24 12 25
2 Main In
Center
10 23 11
3 Main In
Right
21 9 22
4 Main In
Left
Surround
7208
5 Main In
Right
Surround
18 6 19
6 Main In
LFE
4175
7 Cue In
Left
15 3 16
8 Cue In
Right
1142

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
