DigiDesign C24 User Manual

C|24 Guide28
Monitoring System Inputs
Main Inputs and Cue Inputs
Alternate Inputs
External Stereo Inputs
Monitoring System Outputs
Main Outputs (Stereo) and Alternate Outputs
Cue Outputs
Pro Tools In (PT 1-6 + Cue 1-2)
Chan Signal
1 Main Input Left (L) from Pro Tools Out 1
2 no connection
3 Main Input Right (R) from Pro Tools Out 2
4 no connection
5 no connection
6 no connection
7 Cue Input Left from Pro Tools Cue Out 1
8 Cue Input Right from Pro Tools Cue Out 2
Surround In (Alt Sur 1-6)
Chan Signal
1 Alt Input Left (L)
2 no connection
3 Alt Input Right (R)
4 no connection
5 no connection
6 no connection
Ext Stereo In (Ext St 1 + St 2)
Chan Signal
1 Ext Stereo 1 In Left from CD player
2 Ext Stereo 1 In Right from CD player
3 Ext Stereo 2 In Left from DAT deck
4 Ext Stereo 2 In Right from DAT deck
Control Room Out (5.1 Mon Out L:1 R:3)
Chan Signal
1 Main Output Left (L) to Main speaker L
2 no connection
3 Main Output Right (R) to Main speaker R
4 no connection
5 no connection
6 no connection
7 Alt (Stereo) Output Left to Alt speaker L
8 Alt (Stereo) Output Right to Alt speaker R
Alt Outputs (Alt Out L-R on 1/4-inch TRS connectors)
Chan Signal
1 Alt (Stereo) Output Left to Alt speaker L
2 Alt (Stereo) Output Right to Alt speaker R
Cue Outputs (Cue + SLS + TB)
Channel Signal
1 Cue Out Left to cue system
2 Cue Out Right to cue system

DigiDesign C24 Specifications

General

Type	Control Surface
Channels	24
Compatibility	Pro Tools
Faders	24 motorized
Inputs	8 analog line inputs
Outputs	8 analog line outputs
Aux Sends	N/A (Control surface only)
Connectivity	Ethernet, MIDI
Display	LCD scribble strips
Power Supply	External power supply
