DVR Server Manual
【PTZ Baud rate】Select PTZ Baud rate for the PTZ camera.
【PTZ Position】 Select the installation mode of the PTZ according to its
installation mode.
Note:
1) PTZ position will influence PTZ control. E.g.: if you set it as obverse
and press left, then it will turn left. If you set it as inverse and press left,
then it will turn right;
2) If there is (H) after the PTZ protocol, it has the high speed of Preset
function. If there is no (H), it only has ordinary functions;
3) The PTZ address will be sent as a message option. Take care that
some addresses begin from 0. That is to say，when the address
number is 1, the real address is 0. So we must set it according to their
relations.
2.4.2 Motion detection relay & remote client
alert
【DO Port】【 DO Port Name】Select a DO port and set its name to identify
the various DO port. It will be shown as a tip when the mouse moves closely or
above the DO button in DVR Server or NVR Client.
【Camera alarm detected In】Selects camera to be set from dropdown
list.
【Send Alarm to client】Select sending alarm to network clients or not.
【Motion Alarm Sound 】 Press button to selects a “.wav” sound File
for a motion alarm. If there is a motion alarm, the sound file will be played. Also,
you can test it by pressing
button.
【Send email】Set the send email alarm function disable or enable when
the cameras test abnormally
【Send sms】Set the send sms alarm function disable or enable when the
cameras test abnormally.
【Video Loss Alarm Sound 】 Press button to selects a “.wav”
sound File for a video loss alarm. If there is a video loss alarm, the sound file
will be played. Also, you can test it by pressing
button.
【Trigger DO Output】Selects which DO ports will be triggered by above
camera alarms.
Schedule Setup (Setting for cameras of local board cards, IP Cameras
are not included.)
