DVR Server Manual
Next frame: press this button continuously to play video next frame,
the speed is determined by the following playing speed adjustment bar.
/ Play/Pause: The buttons will alternate between Play and Pause.
When it is playing, it shows
. Press it to pause, the button will show .
When you select reverse playing, it will show
to play by pressing it.
Stop: press this button to stop playing.
Image zooms out. Press this button, Left-Single-Click an image;
quarter of the image will be enlarged. Right-Single-Click the image again, it will
resume the normal.
Adjust the voice: drag the bar to adjust the voice
and click the left button to clear the voice.
Adjust playing speed: drag the bar to adjust the
playing speed and click the left button to resume normal playing speed.
Note:
It is not suggested that multi-channel (more than 10 channels) record or
playback coinstantaneous unless your PC has a advanced configuration,
because the data throughput of HDD is huge in that case. Multi-channel search
in client and server are the same except their paths. In client, they are in local;
in remote search, it searches among the record data in server in the local
network.
4.4 Capture picture
Click capture button to capture a still picture. When one is
captured, there will be a dialog to ask for a file name. After your confirmation,
you will be asked to input the save path. When you capture a picture next time,
it will be saved to the previous path without ask you again. But you can modify
or delete the save path in a file named system, with INI as suffix in SetPara.
Note:
The size of the image is that of the playing window.
4.5 Backup
Note:
