DVR Server Manual
display type of OSD & LOGO as well as record resolution, record type, record
quality and frame rate, etc.
【Camera】Select the camera to be set from the drop- list.
【Camera Name】Enter a name description for easy identification.
【Frame Rate】Select the record rate of camera from drop-list.
【Main stream】【 Sub Stream】Select Main stream or Sub Stream for the
current cameras.
【Resolution】Set the resolution at which the video files will be recorded.
Choices are DCIF, CIF, QCIF, 2CIF and 4CIF. The higher the resolution is, the
more disk space needed.
【Stream Type】Select video and audio or only video record.
【Image】Set the quality of the image to be recorded. Select from worst,
worse, normal, good and best.
【Bit Rate Type】Select bit rate type from Variable Bit Rate (VBR) and
Fixed Bit Rate (FBR) record:
VBR range= Poorest, Poor, Medium, Good, Best.
FBR range = 45 Megabytes/Hour to 400 Megabytes/Hour.
【Max Bit Rate】Select the maximum bit rate for Variable Bit Rate (VBR)
record.
【Show LOGO/ OSD/ Week】If you check those boxes, system will show
corresponding information on screen.
【Position】Set the position of OSD or Logo by entering the X and Y
coordinate directly.
【OSD】Set the display attribute of the OSD & LOGO. There are four
types of display modes: Clarity-Glitter, Clarity-Not Glitter, Not Clarity-Glitter and
Not Clarity-Not Glitter.
【OSD Type】Select the type of OSD for the Week.
【Privacy Mask】You can check this box to set the privacy mask on the
below image directly, and you can clear some privacy masks by pressing
button.
【Record schedule】You can set record schedule in following chart.
