DINO 210XT
80
FAULT REMEDY
24. Ball-coupling is not locked
Inner parts of the ball-coupling dirty. Clean and lubricate.
Tow-ball of the towing vehicle too large. Measure the tow-ball. According to DIN74058
the diameter of the ball must be max. 50 mm and
min. 49,5 mm.
If the measure is different or the ball is nor
perfectly spherical, it must be replaced.
Always, when you change brake-shoes, replace all shoes on the axle.
Always when assembling the brakes make sure to install the springs, the brake-shoes and the
expander in the right way.
When adjusting the brakes, turn the wheels forward (in driving direction)!
Naturally the possible reasons for malfunctions are many, but the following are the most
common:
- low supply voltage (long and thin supply cable)
- the battery is flat (low voltage)
- contaminants in the hydraulic system
- loose electric connection or a contact failure caused by moisture
KEEP THE LIFT CLEAN AND PROTECT IT AGAINST MOISTURE
