4.4.3 E1/T1 Status
Click Status & Statistics -> E1/T1 Status in the navigation tree, and the status of each
E1/T1 port is displayed.
Belong to
Parameter
Explanation
Status of
E1/T1 Port
Both physical connection and signal
connection of the E1/T1 port are
normal, and the port is activated.
The E1/T1 port is not used.
Device DSP is not authorized.
Alarm for loss of signal. If the LOS
alarm is raised, please check physical
network connection.
RAI (Remote Alarm Indication) is an
alarm for lost of remote signal. The
alarm is sent by the remote device and
received by MTG200.
AIS (Alarm Indication Signal) is an
alarm raised by MTG200, indicating
the peer device malfunctions, or
signal/physical connections are
abnormal.
This alarm means physical connection
is normal while signal connection is
abnormal.
The E1 port of the device is
automatically shut down when the E1
port intelligent shutdown is enabled
