Dinstar MTG200 - Slave TG Pc Set

MTG200 Trunk Gateway User Manual | Dinstar
48
Parameter
Explanation
No.
The number of the master TG, up to 16 master TGs can be added.
Name
The name of the master TG.
IP Address
The IP address of master TG.
Note：
'Local TG Flag' must be set to 'Master' when 'Slave TG' table is empty!
4.7.8 Slave TG Pc Set
Parameter
Explanation
Slave Tg No.
Slave TG number.
OPC(3-8-3/8-8-8)
OPC: Original Point Code
The signaling point code of MTG200, which is generally assigned by
telecom operators.
DPC(3-8-3/8-8-8)
DPC: Destination Point Code
The signaling point code of the peer device, which is generally
assigned by telecom operators.
