Dionex UltiMate 3000 - Installation; Facility Requirements

UltiMate 3000 RSLCnano – Standard Applications
10
NC_Pump
Loading pump
Rear seal wash system
Flow meter
Purge screws
Inline filter
Purge screw
Tubing guides
Snap-in valves
Column compartment
Figure 6: Detailed overview of the NCS-3500RS interior
Figure 7: Detailed overview of the NCP-3200RS interior, components are identical to the NC_Pump in the NCS-
3500RE
