UltiMate 3000 RSLCnano – Standard Applications
38
Figure 26: Setup for an Automated Off-line 2D Mic Nan experiment using two detectors
The recommended setup using 2 detectors is
presented in Figure 26 and consists of:
SRD-3400 5035.9245
NCS-3500RS 5041.0010
2x 10-port sw.valve 6041.0001
2x VWD-3400RS 5074.0010
3 nL flow cell 6074.0270
180 nL flow cell 6074.0290
WPS-3000PL 5820.0010
µFC option 6820.0051
Application kit: 6720.0330
Tip: The µFC option limits
the upper pressure of the
first dimension to
350 bar, due to the
applied 8-port valve.
