1.3 Replacement Parts
Replacement Parts
Replacement Parts
Item
Category
Part No.
Description
Item
Category
Part No.
Description
1
Push Arm
W7-200
Complete Push Arm-Clear
6
Power Supply Kit
WL-
RS-25-24
(with 17.5” rod)
PWRKIT
Power Supply Kit
W7-205
Complete Push Arm-
Bronze
7
Rocker Switch
W8-804
ON/ OFF/ HOLD OPEN
3 position switch
(with 17.5” rod)
W5-502C
Cast portion - Clear
8
Motor/Gearbox
W8-801
Motor/Gearbox Kit
W5-502B
Cast portion - Bronze
9
Controls
W8-802
HA9 Controller
W5-500C
Extended Rod 22"- Clear
10
Conduit
W8-803
Conduit Bracket Kit
W5-500B
Extended Rod 22"- Bronze
11
Shaft Adaptor
W8-805
Shaft Adaptor
2
Pull Arm Track -
Long
W5-551
Pull Track Assembly Long -
Clear
12
Sync Cable
W8-850
Sync Cable
13
Program Selector
W8-856
Surface Mount Box
W5-556
Pull Track Assembly Long -
Bronze
14
W8-857
2 Position PSK-2
15
W8-858
Spare Key PSK/PS-4C
3
1-9/16” x 2-3/8”
Reveal Spacer
Extrusion
W8-862-
BLK
Spacer Assy. - Black
16
W8-859
4 Position w/Key PS-4C
W8-862-SI
Spacer Assy. - Silver
17
Extension Units
W8-860
EXU-SA
4
Pull Arm
W5-512C
Pull Arm - Clear
18
W8-861
EXU-SI
W5-512B
Pull Arm - Bronze
19
Stop Arm Kit
W8-851
Stop Arm Kit
5
Micro Switch Kit
W8-852
Lock Kick Switch, Cam &
Cable
20
Lock Spacer Kit
W8-853
Lock Spacer Kit
21
Allen Key Head
Nut Kit
W8-854
Allen Key Head Nut Kit
