5.1 Back Check and Latch Adjustment (door stop)
STEP 1
Close the door
Impulses are not accepted if SPTE is more than 0°.
STEP 2
Turn the potentiometer SPTE to 0° (if not already on 0°)
STEP 3
Switch on the mains power (the operator will find its closed position)
STEP 4
Open the door to required open position, plus approx. 5/8" (15 mm), by turning the potentiometer
SPTE on the HA9, clockwise.
