5.6 LRN Learn button for Double doors
For double doors, the master door must be learned first and thereafter the slave door. When the slave door is learned,
the master door will open up to fully open position during the learning phase of the slave door.
The doors can also be learned separately before connecting the sync cable. In case of astragal doors and separate
learning, the master door must be held open before the slave door learn is carried out.
5.7 Learn with advanced setting of “back- and latch-check”
See the prerequisites for performing a "learn" under the heading "Auto-learn
-
automatically sets back and latch check.
(recommended)" on section 4.2
1 Push the button once or twice as for auto-setting.
2 Stop the door at required back-check.
3 The door reverts towards closed position.
4 Remove the stop.
5 Stop the door at required latch-check.
6 The door reverts to learn the fully open position.
7 Remove the stop.
8 The door reverts to closed position.
5.8 Revert to default values for “back- and latch-check”
See the prerequisites for performing a "learn" under the heading "Auto-learn
-
automatically sets back and latch check.
(recommended)" on section 5.4
1 Disconnect the mains contact.
2 Press the "Learn button" and keep it depressed.
3 Connect the mains contact.
4 Watch the "Error LED" lighted for 3 seconds.
5 Release the "Learn button" after 3 seconds (LED is out).
6 The "Back check", "Latch check" and "Open position" have now reverted to default values.
7 Disconnect the mains contact.
8 Next time the mains is connected, the operator will use the default values.
