DKK-TOA WQC-30 User Manual

Model WQC-30 4.2 Affixing and removing the protective cover (optional)
- 29 -
4.2 Affixing and removing the protective cover
(optional)
Injury
●
Handle the instrument unit carefully to avoid damage. I
f
damaged accidentally, fragments may cause injury.
【
IMPORTANT
】
• Please affix and remove the protective cover on a desk or similar so as no
t
to drop the instrument unit. Strong shocks to the instrument unit ma
y
result in damage.
(1) Affixing the protective cover
Insert the instrument unit into the top part of the protective cover and slide it all the way in, as shown in
the diagram.
Protective cover
Instrument unit
Affixing the protective cover
(2) Removing the protective cover
① Lift up the upper strip …… Lift up the upper strip of the protective cover.
Upper band
Protective cover
Lift up the upper strip

DKK-TOA WQC-30 Specifications

General

Brand	DKK-TOA
Model	WQC-30
Category	Measuring Instruments
Language	English
