F6300 Power System Simulator User Guide
72A-2337-01 Rev. B 11/05 3-5
NOTE User defined source selections are not available for F6150/F6300 instrument selection.
Moreover, the source names can be chosen from the available options for each source shown
in the graphic.
3. Assign a name to each source. Name the sources by choosing from active pick lists in the
middle of the display:
• Current sources start with the letter I: i.e., I1, I2, and I3.
• Voltage sources start with a V, i.e.: VA, VB, VC
• Current sources start with an I, i.e.: I1, I2, I3
• Transient current sources start with a T, i.e.: T1, T2, T3
4. Configure the Analog Input fields:
• Type - mAmps or Volts
• Range: - Ranges are dictated by Pre-set selection.
• Sampling Rate - Non-editable
5. Click:
• OK to configure the sources on the F6150/F6300 Instruments.
• Cancel to ignore changes to the source configuration.
• Apply to configure the sources on the F6150/F6300 Instruments without closing the
window.
