Replaceable Components and Cables
5-14 72A-2337-01 Rev. B 11/05
Table 5.5 lists all the cables and cable components used with the F6300.
NOTE If a system failure is traced to a particular cable, ensure that the cable is properly seated and
connected before replacing it. Contact Doble Customer Service to order replacement cables.
Table 5.5 Replacement Components and Cables
Part Number Description
05B-0531-01 Cable, 90A, 5 FT, Black, F2250
05B-0616-01 Assy, Cable, I Output
05B-0619-02 Cable, Adapt #4 R LUG-3x4 mm, F
05B-0662-01 Assy, Cable I PWR Amp Out
181-0088 Cord, Power, 14AWGX3, USA Plug
181-0118 Cable, RG58C/U, 500 HM 20 A M/M
401-0042 Cable, Molded, 5 FT, 15 P, SYNC
401-0157 Terminator, In-line 50 Ohm BNC
401-0160 Adapter, BNC, T, F/M/F
401-0167 Cable, RS-232, INSTR-PC 10 Ft/3.05 Meter
401-0242 Adapter, 10BaseT
401-0243 Cable. ethernet, RJ45/RJ45, 10’
