Communications Parameters
A-4 72A-2337-01 Rev. B 11/05
3. Click OK.
To make the settings in the Set Communications Parameters window the default settings for
future firmware updates, save them in the ProTest INI file:
1. Click Save Settings and the FlashLoader dialog box appears (Figure A.5).
Figure A.5 Flash Loader Save Settings
2. Click Yes to save the settings in the INI file.
NOTE The Flash Loader normally updates the FLASH by communicating with the application that is
already in the FLASH. The link is made using either serial or Ethernet communication. If there
is no valid application in the FLASH, the loader updates the FLASH by communicating with the
boot loader that is already in the FLASH. In this case, the update can only be done using serial
communication.
