TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the Window Switch connector.
Disconnect the BCM C3 harness connector.
Measure the resistance between ground and the Passenger Switch Mux circuit.
Is the resistance below 10000.0 ohms?
All
Yes → Repair the Passenger Window Switch Mux circuit for a short to
ground.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Body Control Module.
Perform BODY VERIFICATION TEST - VER 1.
360
POWER WINDOWS
PASSENGER WINDOW SWITCH SHORT TO GROUND — Continued
To Next Page
