TEST ACTION APPLICABILITY
3 With the ignition OFF.
Measure the coil side resistance of the Headlamp Washer Pump Relay.
Is the resistance between 85.0 and 106.0 ohms?
All
Yes → Replace the Body Control Module.
Perform BODY VERIFICATION TEST - VER 1.
No → Replace the Headlamp Washer Pump Relay.
Perform BODY VERIFICATION TEST - VER 1.
402
WINDSHIELD WIPER & WASHER
HEADLAMP WASHER RELAY SHORT TO BATTERY (EXPORT ONLY) —
Continued
To Next Page
