COOLING
TABLE OF CONTENTS
page page
COOLING
WARNING
COOLING SYSTEM WARNINGS ...........1
SPECIFICATIONS
TORQUE .............................1
SPECIAL TOOLS
COOLING ............................2
ACCESSORY DRIVE .......................3
ENGINE ................................6
COOLING
WARNING
COOLING SYSTEM WARNINGS
WARNING: ANTIFREEZE IS AN ETHYLENE GLYCOL
BASED COOLANT AND IS HARMFUL IF SWAL-
LOWED OR INHALED. IF SWALLOWED, DRINK
TWO GLASSES OF WATER AND INDUCE VOMIT-
ING. IF INHALED, MOVE TO FRESH AIR AREA.
SEEK MEDICAL ATTENTION IMMEDIATELY. DO NOT
STORE IN OPENED OR UNMARKED CONTAINERS.
WASH SKIN AND CLOTHING THOROUGHLY AFTER
COMING IN CONTACT WITH ETHYLENE GLYCOL.
KEEP OUT OF REACH OF CHILDREN AND PETS.
DISPOSE OF GLYCOL BASED COOLANT PROP-
ERLY, CONTACT YOUR DEALER OR GOVERNMENT
AGENCY FOR LOCATION OF COLLECTION CENTER
IN YOUR AREA. DO NOT OPEN A COOLING SYS-
TEM WHEN THE ENGINE IS AT OPERATING TEM-
PERATURE OR HOT UNDER PRESSURE,
PERSONAL INJURY CAN RESULT. AVOID RADIA-
TOR COOLING FAN WHEN ENGINE COMPARTMENT
RELATED SERVICE IS PERFORMED, PERSONAL
INJURY CAN RESULT.
SPECIFICATIONS
TORQUE
DESCRIPTION N·m Ft. Lbs. In. Lbs.
Nut, Accessory
Drive Belt Ten-
sioner
41 30 -
Bolts, A/C Con-
denser to Radiator
5-45
Bolts, Coolant
Pressure Bottle
5-40
Bolts, Fan Shroud
to Radiator
5-45
Hydraulic Fan
Pressure Inlet Line
47 35 -
Hydraulic Fan
Pressure Outlet
Line
29 21 -
Bolts, Radiator
Mounting
11 - 95
Bolts, Thermostat
Housing
11 - 95
Bolts, Water Pump 11 - 95
ZB COOLING 7 - 1
