Splice No. Location Fig.
S142 (Export) In PDC 1
S143 (Export) Near T/O for G100 1
S144 (Export) Left Rear Engine Compartment 8
S146 Near T/O for Park/Turn Lamp - Right 3
S147 Near T/O for Park/Turn Lamp - Right 3
S148 Near T/O for Park/Turn Lamp - Right 3
S149 Near T/O for Park/Turn Lamp - Right 3
S200 Near T/O for G201 20
S201 Near T/O for Low Tire Pressure Warning Module 19
S202 Near T/O for Data Link Connector 18
S203 Near T/O for Brake Lamp Switch 18, 19
S204 In T/O for Window Up Relay - Passenger 18, 19
S205 Near T/O for Low Tire Pressure Warning Module N/S
S206 Near T/O for Instrument Cluster C2 18
S207 Near T/O for Instrument Cluster C2 18
S208 Near T/O for Instrument Cluster C2 18
S209 Near T/O for Airbag Control Module (ORC) C2 18
S210 Near T/O for Glove Box Lamp 18
S212 Near T/O for Glove Box Lamp N/S
S213 In T/O for Radio N/S
S214 Near T/O for Brake Lamp Switch 18, 19
S215 Near T/O for Glove Box Lamp 18
S216 Near T/O for Power Outlet 23
S217 Near T/O for Instrument Cluster C2 18
S218 Near T/O for Data Link Connector 18
S220 In T/O for Window Down Relay - Passenger 18, 19
S221 In T/O for Adjustable Pedal Switch 19
S224 Near T/O for Brake Lamp Switch 18, 19
S226 Near T/O for C101 20
S227 Near T/O for Power Outlet 23
S228 In T/O for C101 20
S229 Center Instrument Panel 18, 19
S230 Near T/O for G201 20
S231 Near T/O for Illuminated Rear View Mirror N/S
S233 (Export) Near T/O For Data Link Connector 18
S246 On Steering Wheel N/S
S247 On Steering Wheel N/S
S250 Near T/O for Blend Door Actuator 16
S251 Near T/O for Blower Motor 17
S300 Near T/O for Starter Motor B(+) 13
S303 Nera T/O for C300 13
S304 Near T/O for Wheel Speed Sensor - Right Rear N/S
ZB 8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 9
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
