Press the assembly profile on the inside of the door onto the door leaf.
Insert the two long screws (2) through the guide slots on the assembly
profile (1) of the cylinder rosette into the drill holes of the door as shown.
Screw the long screws into the threaded bushes so they are hand tight.
It is possible to damage the surface of the lever handle when
fitting the cover.
Do not use any force when installing the covers of handles.
Twist the cover round the lever handle while fitting in order
to avoid contact.
Ensure that the cover and the lever handle do not touch
when fitting the cover.
