1 Coupling nut
2 Spindle hub
3 Door
4 Lever handle bearing inside
5 Spindle
6 Lever handle, inside
7 Adapter sleeve spindle to lever handle inside
8 Adapter sleeve spindle to coupling module of the electronic outer handle
Two AAA 1.5 V lithium batteries are required to supply power to the reading
field. The service life of the batteries stated in the data sheets refers to the
batteries supplied with the product. These can be supplied separately as
accessories or they are available from specialist retailers.
Batteries of a different specification or from a different manufacturer may have
a shorter service life. In this case DOM will not provide any guarantee for the
battery life or the number of possible locking cycles.
The current technical instructions and product information can be found
on the website at www.dom-security.com.
