Combination GUARD with third-party handle
Always install the lever handle fittings/rosettes first for two-part handles. Only
install the cylinder rosettes once the lever handle fittings/rosettes have been
installed.
You must attach the spindle and lever handle to the handle prior to attaching
the handle in position.
The attachment of the lever handle to the electronic handle is described
from page
60 onwards.
The attachment of the spindle is described from page
63 onwards.
The attachment of the spindle with reducing bushes is described from
page 66 onwards.
The short screws which are supplied are only suitable for metal doors
with pre
-cut M5 threads. You can obtain suitable screws for doors made
of different material via s
pecialist retailers.
The screws must be of the same length as the screws supplied and the
heads must be uniform. The head of the short screw must be wider than
the drill hole (5.5
mm). It may have a maximum diameter of 9.8 mm and
mm.
Consult a specialist retailer for advice about suitable short screws for
your door.
You can pre-drill the screwing points in order to guarantee safe
screwing.
You can combine the handles of the GUARD family with third-party handles.
Individual handles can also be supplied in addition to the handle sets for this
purpose. The assembly does not otherwise differ from the procedure
described above.
The manufacturer cannot guarantee compatibility with third-party handles.
Therefore it is necessary to check whether the assembly of third-party handles
with the GUARD handles is possible without difficulties prior to starting the
assembly.
Check whether screwing right through is possible with the third-party
handles.
Otherwise attach the handles by screwing on.
Take the instructions for installing the handle from the corresponding
section for the respective handle variant and attachment method.
