The attachment of the handles differs according to the variant and the
selected type of screwed connection.
The handles of the GUARD family are attached at three points as a rule. In
this process threaded bushes are placed in the handle on the outside. The
threaded bushes are inserted into the corresponding drill holes in the door
leaf. The handle is screwed with long screws in the threaded bushes on the
inside. The screwing is through the door leaf (“Screwing all the way through”).
If using three screw connections is not possible, screwing all the way through
at two points is an alternative.
There is the additional possibility of using short screws on both sides which do
not go right through the door leaf (“Screwing on”) instead of screwing all the
way through.
Danger of injury to the fingers or hands on edges of the
installation profile or the lock.
Wear suitable safety gloves.
Risk of finger or hand injuries caused by slipping during
drilling or screwing work.
Wear suitable safety gloves.
Observe and follow the notices provided in the drilling
machine documentation when drilling.
Damage possible due to screws being too tight.
Damage to the handle, door or lock may result.
Do not use any force when installing handles.
Make sure that the screws are only hand tight.
The manufacturer can provide instructions about the required torque.
