Align lever handle on the mechanical handle
Malfunction due to loss of components on removing the lever
handle
The lever handle return spring can fall out when you release
the attachment screws of the lever handle bearing of a
mechanical GUARD handle. The seamless function of the
lever handle is only guaranteed with the lever handle return
spring.
Do not release the attachment screws of the lever handle
bearing.
If you wish to replace a damaged lever handle, order a
corresponding mechanical assembly profile with pre-
installed lever handle.
The lever handle is already fitted on the assembly profile when the mechanical
handle is delivered. You must align the lever handle to the left or right
according to the installation situation so that the end of the lever handle points
horizontally to the door hinge side.
You can turn the lever handle on mechanical handles at an angle of around
300 ° above the lever handle bearing. You cannot turn the lever handle below
the lever handle bearing.
