1 Inner cover (short plate without reading field)
2 Guide slot for long screw
3 Lever handle
4 Long screw
5 Assembly profile for short plate inside
6 Spindle
7 Threaded bush
8 Battery compartment
9 RFID reading field
10 Assembly profile for outer short plate, with electronic circuit, reading field
and LED display
11 Outer cover (short plate with reading field)
12 Plastic cover for reading field
13 Cover closure of the electronic handle
14 Cover for cylinder rosette inside and outside
15 Screw for screwing on the assembly profiles
16 Assembly profile for cylinder rosette inside and outside
17 Cover closure of the mechanical handle
