Ensure that the lever handle on the inside handle is aligned correctly (see
page 58).
When using adapter sleeves, make sure that these are attached correctly
(see page 66).
Place the lever handle on the spindle protruding on the inside of the door.
Press the assembly profile onto the door leaf.
Insert the three short screws (1) through the guide slots on the assembly
profile as shown.
Damage to the lock possible if screws are too long.
Ensure that the screwing does not damage the lock.
Use shorter screws at screwing points close to the lock if
necessary.
Screw the three short screws into the drill holes so they are hand tight.
Check the lever handle for ease of movement.
Release the centre short screw a little if the lever handle does not move
easily.
Check the lever handle for ease of movement once again.
