Align the outer lever handle horizontally as described from page 60
onwards.
The horizontal positions of the outer lever handle and inner lever handle must
match.
Reattach the cover to the assembly profile.
Installing handle and screwing on
If you cannot attach the handle by screwing right through, you must screw it
on the door with short screws. For this purpose you require two short screws
for the electronic handle and two short screws for both the assembly profile of
the short plates and the cylinder rosette.
Always install the lever handle fittings/rosettes first for two-part handles. Only
install the cylinder rosettes once the lever handle fittings/rosettes have been
installed.
The short screws which are supplied are only suitable for metal doors
with pre
-cut M5 threads. You can obtain suitable screws for doors made
of different material via specialist ret
ailers.
The screws must be of the same length as the screws supplied and the
heads must be uniform. The head of the short screw must be wider than
the drill hole (5.5
mm). It may have a maximum diameter of 9.8 mm and
mm.
Consult a specialist retailer for advice about suitable short screws for
your door.
You can pre-drill the screwing points in order to guarantee safe
screwing.
If you just want to screw the assembly profile on the door with short
screws, you must remove the cover prior to assembly.
It is possible to damage the surface of the lever handle when
removing the cover.
Do not use any force when removing covers from handles.
Twist the cover round the lever handle while pulling it off in
order to avoid contact.
