GENERAL SETTINGS
To view/setup the print head general settings:
1. Select Home > Ink settings > General settings.
2.
Select a Print head tab, to choose which print head to setup.
3.
The settings listed below can now be defined:
Setting Name Explanation
Ink name Displays the ink type.
Ink level (ml) Displays the ink level.
Current print head status Displays the current print head status.
Nozzles status Displays the nozzle status.
Adjust horizontal alignment
(dots)
Fine adjustment of the horizontal alignment.
Adjust vertical alignment
(dots)
Fine adjustment of the vertical alignment.
Selection of nozzle row Select which row of nozzles will print first. Or, if the label's Vertical
resolution (dpi) value is set to 300 - one row, select which row will
print, see Label Defaults on page 101.
Ink level alarm Enable or disable the Ink level alarm.
When the ink level drops to a user specified level, an amber alert
can be displayed.
Warning for ink level
defined at (ml)
If the Ink level alarm is enabled, define the ink level that will trigger
an amber alert.
End of procedure.
CONFIGURATION CODE ACTIVATION
Some special functions are only available if a valid configuration code has been entered.
To activate a configuration code:
1.
Select Home > Setup > Printer configuration > Install configuration.
2.
Enter the configuration code (32 alphanumeric characters).
INSTALLATION
105 EPT053091 - Issue 5 - 07 May 2021
