Domino Gx-Series User Manual

5. Adjust the Distance interval (mm) setting, to set the distance between each label.
1.Notes The distance interval is measured from the start of one label to the start of
the next label.
2. Each label can also have its own "Distance between prints (mm)" value that
will override this setting, when printing is enabled. see Label Settings on
page 134.
Distance Interval Measurement
End of procedure.
I/O FUNCTION ASSIGNMENT
Inputs
To assign functions to I/O inputs:
1. Select Home > Setup > Production line setup > I/O.
2. Select an input and assign a function:
Item Details
Unassigned
No function.
Print Enable Input used for continuous printing. While this input is held activate
and product movement is detected, the print group will print
continuously until product movement stops or the input is
deactivated.
Note The label's Forward oset and Reverse oset
settings define the space between each label, see
Label Defaults on page 101.
Message Increment Increments the printing label.
Message Decrement Decrements the printing label.
Message Reset Resets the label selection back to the original start level.
Message 2^0 Input used for label selection, see External Label Selection on
page 85.
INSTALLATION
EPT053091 - Issue 5 - 07 May 2021 82
