Controller Type Connection Type
Connection Example
Page Reference
Gx-IC7 NPN see Product Detect Sensor NPN
Connection on page 39
Gx-IC7 PNP see Product Detect Sensor PNP
Connection on page 39.
Gx-IC10 or Gx-OEM NPN see Product Detect Sensor NPN
Connection on page 47
Gx-IC10 or Gx-OEM PNP see Product Detect Sensor PNP
Connection on page 48.
3.
Select Home > Setup > Production line setup > Line movement.
4. Select a Print group tab, to choose which print group to setup.
5.
Select the Encoder input setting and select External - 1 Photocell.
End of procedure.
2 PHOTOCELL ENCODER SETUP
WARNING Hazardous Chemicals. Risk of eye and skin damage.
Wear protective equipment such as gloves and glasses when near the
printer.
Contact with chemicals can cause skin or eye damage.
Refer to Safety Data Sheet.
When the leading edge of a product passes the first photocell on the production line, the
photocell sends an input to the controller. A second input is sent to the controller when the
leading edge of the product passes the second photocell. The the distance between each
photocell is saved in the controller's settings. The controller uses the calculation below to
identify the production line speed:
INSTALLATION
77 EPT053091 - Issue 5 - 07 May 2021
