Domino Gx-Series User Manual

PRINT HEADS
Print heads are connected to the controller via an electrical cable. There are four cable lengths
available: 3, 6, 12 and 25 metres.
Print heads can be installed together in groups. Print head groups allow taller labels and higher
print density. Print heads in groups can also alternate printing, to reduce downtime when
changing ink cartridges.
Note
Consult Domino if stitch barcodes are required.
Standard Print Head
The standard print head has a socket for connection to the controller at the top.
Standard Print Head
Multi Print Head
The multi print head has a socket connector that can be moved to the front or rear of the print
head. This allows the print head to be installed in areas with dierent space restrictions, see
Multi Print Head Socket Relocation on page 53.
Multi Print Head
SYSTEM DESCRIPTION
13 EPT053091 - Issue 5 - 07 May 2021
