Domino Gx-Series User Manual

# Description # Description
A RS232 E Power Supply Input
B I/O 1 and 2 F Ethernet
C Encoder G USB
D Print Head 2 H Print Head 1
Gx-IC10
WARNING
Electricity. Risk of injury.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the controller contains live electrical components.
Physical contact with live electrical components can result in an electric
shock.
CAUTION
Electricity. Risk of damage to equipment.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the equipment contains live electrical components.
An incorrect electrical connection can damage the equipment.
Gx-IC10 Connections
# Description # Description
A Fieldbus Module (Optional) H Encoder 1
INSTALLATION
31 EPT053091 - Issue 5 - 07 May 2021
