Doosan DVF5000 - Machine Transport and Checking of Shipped Items; Machine Transport

9
1. Preparation Before Machine Shipping
No. Parts No. Description Mat./Specification Q’ty Remarks
10 P88073613 Leveling Bolt S45C 6
Level
Block
20 P88100036 Hex. Nut S45C 6
30 00201-04106 Leveling Block GC250 6
40 100203-01052 Clamp; Z S45C 4
Side
Anchor
(Optional)
50 120112-01428 Clamp Bolt HIT-C M20×320 4
60 S5101101 Spring Washer ZS20 4
70 S5001101 Plane Washer ZP20 4
80 S4001132 Hex. Nut NA M20×16 4
90 850419-00065 Screw Jack SJ130 4
※
Side Anchor Parts List
10
20
30
80
60
70
40
90
50
