Doosan DVF5000 - B-axis Reference Point Resetting (B-axis Stroke: B-30° ∼ B110°)

82
7. Adjustment of reference points of respective axes and manual TCP adjustment
Z-axis
reference
point mark
Z-axis fixing
reference
point mark
Z-axis feed
reference
point mark
+ direction
- direction
Grid
Grid
Grid
Reference
point mark
Starting position
Grid Shift (Parameter No. 1850)
