26 Instructions for use | Atlan A300, A300 XL, A350, A350 XL SW 1.0n
Overview
3.1.9 Gas inlets
36475
No. Designation Description
1 Connectors for pressure mea-
suring lines for gas cylinders
(option)
Used for connecting pressure measuring
lines of the pressure reducers on the gas
cylinders.
2 Connectors for central gas
supply system
Enable the device to be supplied with gases
from the central supply.
3 Connectors for gas cylinders
(option)
Enable the device to be supplied with gases
from the gas cylinders.
4 Label Advanced Cylinder Sup-
port
On devices that are equipped with
Advanced Cylinder Support, the gas cylin-
der valves can also remain open during
operation with the central supply.
