116 Instructions for use | Atlan A300, A300 XL, A350, A350 XL SW 1.0n
Operation
7.9 Adjusting the alarms
7.9.1 Setting the alarm limits
For a current case, the alarm limits can be set in 2 ways:
– Setting using the Quick setup dialog
– Setting using the Alarms dialog
Setting using the Quick setup dialog
1. Touch the respective waveform or the parameter field.
2. Set the upper alarm limit (1).
3. Set the lower alarm limit (2).
Manual setting
In the Alarms dialog, the alarm limits can be set either manually or automatically.
1. Open the Alarms dialog.
2. Open the Limits tab (1).
3. Set the upper alarm limit (2).
4. Set the lower alarm limit (3).
3592235935
1
2
Quick setup
45
2
3
1
Alarms
