320 Instructions for use | Atlan A300, A300 XL, A350, A350 XL SW 1.0n
Annex
Ambient pressure
Do not use if package damaged
Do not reuse
Spare part
LAN connection
USB port
Identifies the interface for the workstation light
External fresh-gas outlet
CO
2 absorber bypass
Enter key
Indicates a changed view which has not yet been saved
Identifies the tabs that lead to the page with the language set-
tings.
Read the flow at the center of the float.
Advanced Cylinder Support
Identifies N
2O cylinders.
The color code conforms to the locally applicable standard.
Identifies O
2 cylinders.
The color code conforms to the locally applicable standard.
Identifies Air cylinders.
The color code conforms to the locally applicable standard.
Maintain the correct minimum distance between electrical con-
nectors and gas cylinders, see product label on the device.
Electrical connector on the device
When connecting auxiliary devices, be aware of the leakage
current.
Observe chapters "Assembly and preparation" and
"Technical data".
Gas outlet
Gas inlet
Symbol Explanation
