Dräger Isolette 8000 plus - Page 65

Instructions for use Isolette 8000 plus SW 5.n 65
Getting started
1 In the skin temperature mode, disconnect the skin probe from the central skin
probe connector of the sensor module.
 The skin display goes blank.
 The Central Probe Missing alarm message is displayed in the
Trend/Alarm window.
 The acoustic alarm signal sounds.
2 Press the Audio Paused/Reset key.
 The acoustic alarm signal silences for 5 minutes.
3 Reconnect the skin probe in the central skin probe connector.
 The incubator returns to normal operation.
6 Check the maximum air temperature.
1 Connect a central skin probe to the sensor module, and select skin
temperature mode.
2 In the temperature override mode, select a temperature >37 °C (see Skin
temperature mode on page 79).
3 Place the skin probe outside the incubator.
4 Allow the incubator to heat.
5 If the High Temp CutOut alarm sounds, press the Audio Paused/Reset
key.
6 Verify that the incubator does not heat above 39.9 °C (103.82 °F) as
indicated on the screen.
7 Check the Connect Central Skin Probe alarm.
1 While operating in the air temperature mode, disconnect the central skin
probe.
2 Select the skin temperature mode.
 The Connect Central Skin Probe alarm sounds.
8 Check the screen intensity feature at the system displays (see Keys on page
41).
 Use the Up Arrow key to increase the screen intensity 3 levels.
 Use the Down Arrow key to decrease the screen intensity 3 levels.
7.2.2 Hood/shell functional check
1 Check the access panels:
1 Rotate the locking knobs, and open the front access panel.
 At the controller screen, the access panel open symbol ( ) appears.
