23
Accessories
Accessories
The accessories shown in the order list on page 80 are available for the gas transmitter.
Depending on the accessories that have been installed, there may be deviations to the
performance characteristics (to some extent see "Performance Characteristics (typical
values)" on page 73 and page 74)!
Overview of Accessories for the Dräger PIR 7000 / Dräger PIR 7200
From the technical point of view, the accessories for the Dräger PIR 7000 and the Dräger
PIR 7200 gas transmitters described in this chapter are basically identical. The accessories
splash guard, status indicator, flowcell and bump test adapter are each available in two
models, as the different measurement tasks (Dräger PIR 7000 = flammable gases and
vapours and Dräger PIR 7200 = carbon dioxide) are to be distinguished using different
colours. For Dräger PIR 7000, the selected colour is red, for Dräger PIR 7200 it is white.
04623886_01.eps
11 8
7
6
3
4
9
10
5
1
12
2
