EL7.5 - EL12.5 (S - SS) User manual - ENG 25/70
- check the tightness of the agitator [10] and all the other threaded components
of the agitator kit (see Fig. 6): in detail, be careful to the full tightening of the
connector element [11] and the nut [12] in order to ensure a complete and
strong contact between the spacer [13] and the impeller [1] (see Fig. 6);
Fig. 6
[12]
[10]
[11]
[13]
[1]
