26
Annex Specifies the modulation standard used for the ADSL connection.
VPI / VCI Set values for Virtual Path Identifier(VPI) and Virtual Channel
Identifier(VCI).
Customer VLAN Enabled - Switch the toggle to enable or disable the function. If
enabled, enter the values for the tag and priority.
Tag - Enter the value as the VLAN ID number. The range is from 0 to
4094.
Priority - Enter the packet priority number for such VLAN. The range
is from 0 to 7.
VDLS2 Setting
Customer VLAN Enabled - Switch the toggle to enable or disable the function. If
enabled, enter the values for the tag and priority.
Tag - Enter the value as the VLAN ID number. The range is from 0 to
4094.
Priority - Enter the packet priority number for such VLAN. The range
is from 0 to 7.
Service VLAN Enabled - Switch the toggle to enable or disable the function. If
enabled, enter the values for the tag and priority.
Tag - Enter the value as the VLAN ID number. The range is from 0 to
4094.
Priority - Enter the packet priority number for such VLAN. The range
is from 0 to 7.
IPv4
IPv4 Connection Type Specify the Internet Access Type (PPPoE, PPPoA, Static IP, DHCP).
Username Enter the username provided by the ISP if PPPoE / PPPoA is selected
as IPv4 Connection Type.
Password Enter the password provided by the ISP if PPPoE / PPPoA is selected as
IPv4 Connection Type.
IP Address Enter the WAN IP address of the router if Static IP is selected as IPv4
Connection Type.
Subnet Mask Enter the subnet mask of the router if Static IP is selected as IPv4
Connection Type.
Gateway IP Enter the IP address of the remote gateway if Static IP is selected as
IPv4 Connection Type.
DNS
IPv4 Primary Server Enter the IP address of the primary DNS server.
IPv4 Secondary Server Enter the IP address of the secondary DNS server.
Back Return to previous setting page.
Cancel Discard current settings and return to the previous page.
Next Get into the next setting page.
