Vigor2926 Series User’s Guide
302
Local ID – Choose Alternative Subject Name First or Subject
Name First.
Local Certificate – Use the drop down list to choose one of
the certificates for using. You have to configure one
certificate at least previously in Certificate Management >>
Local Certificate. Otherwise, the setting you choose here
will not be effective.
IPsec Security Method
Medium - Authentication Header (AH) means data will be
authenticated, but not be encrypted. By default, this option
is active.
High - Encapsulating Security Payload (ESP) means payload
(data) will be encrypted and authenticated. You may select
encryption algorithm from Data Encryption Standard (DES),
Triple DES (3DES), and AES.
User Name This field is used to authenticate for connection when you
select PPTP or L2TP with or without IPsec policy above.
The length of the user name is limited to 11 characters.
Password This field is used to authenticate for connection when you
select PPTP or L2TP with or without IPsec policy above.
The length of the password is limited to 11 characters.
Remote Network IP Please type one LAN IP address (according to the real
location of the remote host) for building VPN connection.
Remote Network
Mask
Please type the network mask (according to the real location
of the remote host) for building VPN connection.
3. After finishing the configuration, please click Next. The confirmation page will be
shown as follows. If there is no problem, you can click one of the radio buttons listed on
the page and click Finish to execute the next action.
Available settings are explained as follows:
Item Description
