DSC Neo - Page 124

Section 6: Programming Worksheets
202 – Partition 2 Command Output
Labels
001 – Partition 2 Command Output 1:
(2 X 14 ASCII) 002 – Partition 2 Command Output 2:
003 – Partition 2 Command Output 3:
004 – Partition 2 Command Output 4:
203 – Partition 3 Command Output
Labels
001 – Partition 3 Command Output 1:
(2 X 14 ASCII) 002 – Partition 3 Command Output 2:
003 – Partition 3 Command Output 3:
004 – Partition 3 Command Output 4:
204 – Partition 4 Command Output
Labels
001 – Partition 4 Command Output 1:
(2 X 14 ASCII) 002 – Partition 4 Command Output 2:
003 – Partition 4 Command Output 3:
004 – Partition 4 Command Output 4:
205 – Partition 5 Command Output
Labels
001 – Partition 5 Command Output 1:
(2 X 14 ASCII) 002 – Partition 5 Command Output 2:
003 – Partition 5 Command Output 3:
004 – Partition 5 Command Output 4:
206 – Partition 6 Command Output
Labels
001 – Partition 6 Command Output 1:
(2 X 14 ASCII) 002 – Partition 6 Command Output 2:
003 – Partition 6 Command Output 3:
004 – Partition 6 Command Output 4:
207 – Partition 7 Command Output
Labels
001 – Partition 7 Command Output 1:
(2 X 14 ASCII) 002 – Partition 7 Command Output 2:
003 – Partition 7 Command Output 3:
004 – Partition 7 Command Output 4:
208 – Partition 8 Command Output
Labels
001 – Partition 8 Command Output 1:
(2 X 14 ASCII) 002 – Partition 8 Command Output 2:
003 – Partition 8 Command Output 3:
004 – Partition 8 Command Output 4:
601 – Schedule 1 Label
(1 X 16 ASCII):
Descriptions on page 63
602 – Schedule 2 Label
(1 X 16 ASCII):
603 – Schedule 3 Label
(1 X 16 ASCII):
604 – Schedule 4 Label
(1 X 16 ASCII):
[000]
801 – Keypad Labels (1 X 14 ASCII) Description on page 63
- 124 -
