DSC Neo User Manual

Section 6: Programming Worksheets
001 – Keypad 1 Label: 009 – Keypad 9 Label:
002 – Keypad 2 Label: 010 – Keypad 10 Label:
003 – Keypad 3 Label: 011 – Keypad 11 Label:
004 – Keypad 4 Label: 012 – Keypad 12 Label:
005 – Keypad 5 Label: 013 – Keypad 13 Label:
006 – Keypad 6 Label: 014 – Keypad 14 Label:
007 – Keypad 7 Label: 015 – Keypad 15 Label:
008 – Keypad 8 Label: 016 – Keypad 16 Label:
802 – HSM2108 Zone Expander Label Description on page 63
001– Zone Expander 1 Label: 009– Zone Expander 9 Label:
002– Zone Expander 2 Label: 010– Zone Expander 10 Label:
003– Zone Expander 3 Label: 011– Zone Expander 11 Label:
004– Zone Expander 4 Label: 012– Zone Expander 12 Label:
005– Zone Expander 5 Label: 013– Zone Expander 13 Label:
006– Zone Expander 6 Label: 014– Zone Expander 14 Label:
007– Zone Expander 7 Label: 015– Zone Expander 15 Label:
008– Zone Expander 8 Label:
803 – HSM2208 Output Expander Label (1 X 14 ASCII) Description on page 63
001– Output Expander 1 Label: 009– Output Expander 9 Label:
002– Output Expander 2 Label: 010– Output Expander 10 Label:
003– Output Expander 3 Label: 011– Output Expander 11 Label:
004– Output Expander 4 Label: 012– Output Expander 12 Label:
005– Output Expander 5 Label: 013– Output Expander 13 Label:
006– Output Expander 6 Label: 014– Output Expander 14 Label:
007– Output Expander 7 Label: 015– Output Expander 15 Label:
008– Output Expander 8 Label: 016– Output Expander 16 Label:
[000]
806 – HSM2HOSTx Label:
(1 X 14 ASCII) Description on page 63
[000]
808 - HSM2955 Audio Module Label:
[000]
809 – HSM2300 Power Supply Label
001 – Power Supply 1 Label:
(1 X 14 ASCII) 002 – Power Supply 2 Label:
003 – Power Supply 3 Label:
004 – Power Supply 4 Label:
[000]
810 – HSM2204 High-Current Output Supply
Label
001 – High-Current Output Supply 1 Label:
(1 X 14 ASCII) 002 – High-Current Output Supply 2 Label:
Description on page 64 003 – High-Current Output Supply 3 Label:
004 – High-Current Output Supply 4 Label:
- 125 -

DSC Neo Specifications

General

Model	DSC Neo
Category	Security System
Partitions	Up to 8
Type	Hybrid Security System
Zones	Up to 128 zones
Communication	Cellular, IP
Compatibility	PowerG wireless sensors
Remote Access	Yes, via app
PGMs	4
Wireless Range	Up to 2 km with PowerG
Event Buffer	1000 events
Wireless Frequency	433 MHz, 868 MHz
Power Supply	16.5VAC, 40VA
Battery Backup	Yes, 12VDC 7Ah
Operating Temperature	0°C to 49°C (32°F to 120°F)
Event Log	Yes
